Ashva 4S

#ReachTheUnreached

Download Brochure

engine & drivetrain
Engine Type	XTR - 4 stroke, V-twin, Differential Integrated, Liquid Cooling PFX - 4 stroke, V-twin, Liquid cooling
Power	XTR - 976 cc, 71 hp (53.7kw) @ 6500 RPM PFX - 976 cc, 85.4 hp (63.7kw) @ 6500 RPM
Fuel System	EFI, Gasoline
Ignition System	Electric Start
Transmission	Automatic (CVT)
No. of Gears	L - H - N - R - P (5 positions)
suspension
front shocks	DUAL RATED COIL OVER WITH NITRO CHARGE PIGGYBACK CANISTER
front suspension	double wishbone suspension
Rear Shocks	DUAL RATED COIL OVER WITH NITRO CHARGE REMOTE CANISTER
Rear Suspension	TRAILING ARM WITH TRIPLE CAMBER LINKS
brakes & tires/rim
Front & Rear	Disc Brake
Front Tires	31 x 10.5
Rear Tires	31 x 10.5
Wheel Size	Alloy Wheels R15- 7”
DIMENSIONs
Length	4320 mm
Width	1950 mm
Height	2000 mm
Wheelbase	3412 mm
Track width	1550 mm
Payload Capacity	700 Kg
Dry Weight	1300 Kg
Fuel Tank Capacity	30 L
Ground Clearance	381 mm
Cargo Capacity	60 L
FEATURES
CARGO SYSTEM	inbuilt cargo box
Transmission Modes	2WD, 4WD, Front & Rear + Open & Lock Differential Modes
Chassis/ Cage	Space Frame
HITCH TYPE	Single Point (Front & Rear)
Lighting	Halogen
Seat Belt	4-point/ 5 point
Seat Type	Bucket Seat
Seating Capacity	4 Seater
Instrumentation	Semi Digital Instrument Cluster
Snorkel	Inlet & Outlet for CVT
Gravel Guard	Yes

Attachment Integration Capabilities
Tow behind trailer
3-point hitch
Rear hitch carrier
Agri attachment without PTO

Terms & Conditions- Tested on A-thon Test Track without any attachments
Specifications subjected to change due to periodic upgrades in the product & technology
All parameters may slightly vary from the actual specifications
As per A-THON recommended attachments
